General Features
● Max. PV voltage up to 1000V
● High efficiency up to 98.1%
● Redundancy control circuits
● High performance redundancy cooling system
● Advanced DSP control
● Zero Voltage Ride Through function
● Reactive power controller
● SVG function at night
Technical Parameters
| Model | GSL0100T | GSL0250T | GSL0500T |
| Input(DC) | |||
| Max. DC power | 110KW | 275KW | 550KW |
| Max. DC voltage | 1000Vdc | ||
| MPPT voltage range | 450~850Vdc | ||
| Number of MPPT trackers | 1 | ||
| Max. input current | 240A | 600A | 1200A |
| Output(AC) | |||
| Raled output power | 100KW | 250KW | 500KW |
| Raled output voltage | 400Vac | ||
| AC output topology | 3W+N+PE | ||
| Output voltage range | (1±15%)*Normal AC Voltage (adjustable ±5%，±10%，±15%，±20%) | ||
| Grid frequency range | 50 / 60Hz（±4.5Hz），（adjustable） | ||
| Rated AC output current | 144A | 361A | 722A |
| Max. output current | 158A | 397A | 794A |
| Power factor (cosФ) | 1（Lagging0.9~Leading0.9）（adjustable） | ||
| THDI | ＜3% | ||
| Efficiency | |||
| Max. efficiency | 97.70% | 97.90% | 98.10% |
| Euro efficiency | 97.40% | 97.60% | 97.90% |
| MPPT efficiency | ＞99% | ||
| Standby（night time）losses | ＜10W | ||
| Cooling | Forced air cooling | ||
| Protection rating | IP21 | ||
