General Features
● Max. PV voltage up to 1000V
● High efficiency up to 98.7%
● Redundancy control circuits
● High performance redundancy cooling system
● Advanced DSP control
● Zero Voltage Ride Through function
● Reactive power controller
● SVG function at night
Technical Parameters
|
Model |
GSL0500 |
GSL0630 |
GSL0750 |
|
Input(DC) |
|||
|
Max. DC power |
550KW |
690KW |
825KW |
|
Max. DC voltage |
1000Vdc |
||
|
MPPT voltage range |
450~850Vdc |
500~850Vdc |
|
|
Max. DC input number |
8 |
10 |
|
|
Max. input current |
1200A |
1440A |
1500A |
|
Output(AC) |
|||
|
Raled output power |
500KW |
630KW |
750KW |
|
Raled output voltage |
315Vac |
350Vac |
|
|
AC output topology |
3W+PE |
||
|
Output voltage range |
(1±15%)*Normal AC Voltage (adjustable ±5%，±10%，±15%，±20%) |
||
|
Grid frequency range |
50 / 60Hz（±4.5Hz），（adjustable） |
||
|
Rated AC output current |
916A |
1155A |
1237A |
|
Max. output current |
1007A |
1264A |
1360A |
|
Power factor (cosФ) |
1（Lagging0.9~Leading0.9）（adjustable） |
||
|
THDI |
＜3% |
||
|
Efficiency |
|||
|
Max. efficiency |
98.7% |
||
|
Euro efficiency |
98.5% |
||
|
MPPT efficiency |
＞99% |
||
|
Standby（night time）losses |
＜10W |
||
|
Cooling |
Forced air cooling |
||
|
Communication interface |
RS485, external Ethernet (optional) |
||
