General Features
● Max. PV voltage up to 1000V
● High efficiency up to 98.7%
● Redundancy control circuits
● High performance redundancy cooling system
● Advanced DSP control
● Zero Voltage Ride Through function
● Reactive power controller
● SVG function at night
Technical Parameters
|
Model |
GSL1000 |
GSL1250 |
|
Input(DC) |
||
|
Max. DC power |
1300KW |
1562KW |
|
Max. DC voltage |
1000Vdc |
|
|
MPPT voltage range |
580~850Vdc |
|
|
Max. DC input number |
8(320A) / 16(160A) |
|
|
Max. input current |
1935A |
2420A |
|
Output(AC) |
||
|
Raled output power |
1000KW |
1250KW |
|
Raled output voltage |
400Vac |
|
|
Output voltage range |
(1±15%)*Normal AC Voltage (adjustable ±5%，±10%，±15%，±20%) |
|
|
Grid frequency range |
50 / 60Hz（±4.5Hz），（adjustable） |
|
|
Rated AC output current |
1444A |
1804A |
|
Max. output current |
1588A |
1984A |
|
Power factor (cosФ) |
1（Lagging0.9~Leading0.9）（adjustable） |
|
|
THDI |
＜3% |
|
|
Efficiency |
||
|
Max. efficiency |
99.0% |
|
|
Euro efficiency |
98.7% |
|
|
MPPT efficiency |
＞99% |
|
|
Standby（night time）losses |
＜50W |
|
|
Cooling |
Forced air cooling |
|
|
Communication interface |
RS485, external Ethernet (optional) |
|
