General Features
● Max. PV voltage up to 1500V
● Max. 12 DC inputs
● Dustproof protection
● Modular design for Easy maintenance
● Max. DC/AC ratio up to 1.5
● Full power output under 55℃
● AGC/AVC,LVRT/HVRT/FRT function
● SVG function at night
Technical Parameters
|
Model |
GSM1250 |
GSM1500 |
|
Input(DC) |
||
|
Max. DC voltage |
1500Vdc |
|
|
MPPT voltage range |
800~1300Vdc |
900~1300Vdc |
|
Max. DC input number |
10 |
12 |
|
Max. input current |
1750A 1870A |
|
|
Output(AC) |
||
|
Rated output power |
1250KW |
1500KW |
|
Rated output voltage |
550Vac |
600Vac |
|
Output voltage range |
(1±10%)×Rated AC Voltage (adjustable ±5%,±10%,±15%) |
|
|
Grid frequency range |
50 / 60Hz（±4.5Hz）（adjustable） |
|
|
Rated AC output current |
1312A |
1443A |
|
Max. AC output current |
1443A |
1443A |
|
Power factor (cosФ) |
1 ( 0.9 leading – 0.9 lagging) (adjustable) |
|
|
THDI |
＜3% |
|
|
Efficiency |
||
|
Max. efficiency |
99.0% |
|
|
Euro efficiency |
98.7% |
|
|
MPPT efficiency |
＞99% |
|
|
Standby（night time）losses |
＜50W |
|
|
Cooling type |
Forced air cooling |
|
|
Communication interface |
RS485, external Ethernet (optional) |
|
