General Features
● Max. PV voltage up to 1000V
● High efficiency up to 99%
● Redundancy control circuits
● High Performance redundancy cooling system
● Advanced DSP control
● Zero Voltage Ride Through function
● Reactive power controller
● SVG function at night
● IP54 protection
● Fast installation and convenient maintenance
Technical Parameters
|
Model |
GSL2000C |
GSL2500C |
|
Input(DC) |
||
|
Max. DC input power |
2600KW |
3124KW |
|
Max. DC voltage |
1000Vdc |
|
|
MPPT voltage range |
580~850Vdc |
|
|
Number of mppt trackers |
16(320A) / 10(504A) |
|
|
Max. input current |
3870A |
4840A |
|
Output(AC) |
||
|
Raled output power |
2000KW |
2500KW |
|
Raled output voltage |
400Vac |
|
|
Output voltage range |
(1±15%)*Normal AC Voltage (adjustable ±5%，±10%，±15%，±20%) |
|
|
Grid frequency range |
50 / 60Hz（±4.5Hz），（adjustable） |
|
|
Rated AC output current |
2888A |
3608A |
|
Max. output current |
3176A |
3968A |
|
Power factor (cosФ) |
1（Lagging0.9~Leading0.9）（adjustable） |
|
|
THDI |
＜3% |
|
|
Efficiency |
||
|
Max. efficiency |
99.0% |
|
|
Euro efficiency |
98.7% |
|
|
MPPT efficiency |
＞99% |
|
|
Standby（night time）losses |
＜50W |
|
|
Cooling |
Forced air cooling |
|
|
Communication interface |
RS485, external Ethernet (optional) |
|
