Products Description
A 3KW Hybrid Solar System is an advanced energy solution that integrates solar photovoltaic panels, hybrid inverters, and battery storage systems. It generates clean electricity from solar energy, stores excess power in batteries for use at night or on cloudy days, and supports seamless connection to the grid. This system combines the advantages of grid-tied and off-grid setups, providing uninterrupted power supply, improving energy utilization efficiency, and reducing reliance on fossil fuels. It is suitable for residential, commercial, or remote area power needs.
System Block Diagram
System Overview
Model info
Model NO
SF3K-Hybrid
Rated Power
3KW
Output
AC230V50/60Hz
Certification
CE/TUV
Hybrid Inverter
Tier-1 brand Inverter
PV module
Shinefar Solar N-type high efficiency PV module
Battery
High quality LifePo4 cells inside
Mounting Structure
Roof/Ground Customized
System Configuration
|
PV module 580W |
6pcs |
9pcs |
14pcs |
|
Hybrid Inverter |
R3KL1-G2 |
R5KL1-G2 |
R8KL1-G2 |
|
Wi-Fi Module |
|
|
|
|
Mounting System |
1 set |
1 set |
1 set |
|
DC cable 4mm² |
50M |
100M |
150M |
|
PV connector |
10 kit |
15 kit |
20 kit |
|
PV combine box |
1 set |
1 set |
1 set |
| PV Tools Wire Cable Cutter &Stripper, Crimping Pliers for PV Connectors (Opt) | |||
System Components
Shinefar Solar PV module
Technology: Utilizing MBB half cell N-type TOPCon
Pmax: 580W
Vmp: 42.91V
Imp: 13.52A
Voc: 50.80V
Isc: 14.55A
Dimensions: 2278×1134×30mm Weight: 26.5kg
Shinefar Hybrid Inverter
Using soft switching technology, the overall machine efficiency is increased by 0.5%.
Support AC coupling function.
Support mobile phone (Bluetooth +WlFl) setting and maintenance.
Compact design Save 50% on installation costs.
Ultra-low starting voltage, longer power generation time.
Shinefar Solar Lithium Battery
Safer|Reliable|Flexble|Convenient|Eco-Friendly
Battery Chemistry: LiFePO4
Capacity (Ah): 100
Scalability: Max 64
Nominal Voltage (V): 51.2
Operating Voltage(V): 43.2~57.6
Nominal Energy (kWh): 5.12
Charge/DischargeCurrent(A):
Recommend: 50
Max.: 100
Peak(2mins,25℃): 120
Shinefar Solar PV Combine Box
Cross Section: 4mm², 6mm² Optional
Rated Voltage: DC500V/1000VDC/1500V(TUV)
Rated Current: 15A or higher
surge protection
Mounting Structure
Residential Roof(Pitched Roof)
Commercial Roof(Flat roof&workshop roof)
Ground Solar Mounting system
Vertical wall solar mounting system
All aluminum structure solar mounting system
Car parking solar mounting system
Our Advantages
WHY CHOOSE US?
Certificates
FAQ
What is the lifespan of the solar panels and batteries in a 3KW hybrid solar system?
+
-
The lifespan of solar panels is generally about 30 years, while the batteries last for about 5-10 years depending on usage and maintenance.
Can a 3KW hybrid solar system be connected to the grid?
+
-
Yes, a 3KW hybrid solar system can be connected to the grid. This allows any excess power generated by the system to be fed back into the grid for others to use. Additionally, if the solar panels do not generate enough power to meet the household's needs, the grid can provide the difference.
Is it possible to customize the 3KW hybrid solar system?
+
-
Yes, it is possible to customize the system to meet specific needs. The system can be designed to accommodate varying energy requirements, depending on the size of the household and the appliances in use. Additionally, it is possible to customize the system to include monitoring and control capabilities or to integrate with smart home systems.
